Key Specs
| John Deere 1835 | Spacing | Width |
|---|---|---|
| Spacing and width #1 | 10 in (25.4 cm) | 41 ft (12.5 m) |
| Spacing and width #2 | 10 in (25.4 cm) | 50 ft (15.2 m) |
| Spacing and width #3 | 10 in (25.4 cm) | 61 ft (18.6 m) |
Dimensions
| Road clearance with sweep | 16 in (40.6 cm) |
| Transport width (3-section model) | 20.3 ft (6.2 m), 41 ft (12.5 m) |
| Transport width (5-section model) | 20.3 ft (6.2 m), 20.5 ft (6.25 m), 50 ft (15.2 m), 61 ft (18.6 m) |
| Nominal mainframe width (between wing-fold pivots) | 13.75 ft (4.19 m) |
| Spacing and width #1 | |
|---|---|
| Working width | 40 ft (12.2 m) |
| Transport height without harrow | 18.28 ft (5.57 m) |
| Minimum temporary height reduction with sweeps | 20 in (508 mm) |
| Weight with typical options | 29000 lb (13154 kg) |
| Spacing | 10 in (25.4 cm) |
| Width | 41 ft (12.5 m) |
| Spacing and width #2 | |
| Working width | 50 ft (15.2 m) |
| Transport height without harrow | 15.75 ft (4.8 m) |
| Minimum temporary height reduction with sweeps | 20 in (508 mm) |
| Nominal inner wing width (between wing-fold pivots) | 10.1 ft (3.08 m) |
| Weight with typical options | 37575 lb (17044 kg) |
| Spacing | 10 in (25.4 cm) |
| Width | 50 ft (15.2 m) |
| Spacing and width #3 | |
| Working width | 60 ft (18.3 m) |
| Transport height without harrow | 19.02 ft (5.8 m) |
| Minimum temporary height reduction with sweeps | 20 in (508 mm) |
| Nominal inner wing width (between wing-fold pivots) | 13.59 ft (4.14 m) |
| Weight with typical options | 41425 lb (18790 kg) |
| Spacing | 10 in (25.4 cm) |
| Width | 61 ft (18.6 m) |
Seed Opener
| Spacing | 10, 12.5 in (25.4, 31.75 cm) |
| Dimensions | 1.25 x 2 x 28 in (31.75 x 50.8 x 711 mm) |
| Trip force 51 degree | 550 lbf (2.45 kN) |
| Tru-Position™ (angle) | 51 degree |
| Underframe clearance | 28 in (71.12 cm) |
Fertilizer Opener
| Spacing | 20 in (508 mm) |
| Blade size | 18 in (457 mm) |
| Fertilizer compatibility | Anhydrous gas, liquid, dry |
| Type | Rolling disk |
Mainframe
| Centerframe width | 13.75 ft (4.19 m) |
| Cross members | 4 x 4 in (10.16 x 10.16 cm) |
| End tubes | 4 x 4 x 3/8 in (102 x 102 x 9.5 mm) |
| Hitch Pin | 2 in (50.8 mm) |
| Hitch category | Category IV |
| Seeding tool depth control | Adjustable mechanical stop |
| Mainframe and wing flexibility | Diagonal flex |
Fore-Aft Dimensions
| Hitch pin to rear of transport wheels | 33.2 ft (10.12 m) |
| Lateral frame clearance, opener to opener | 30 in (76.2 cm) |
| Fore-aft frame clearance between ranks | 29 in (73.66 cm) |
| Front of front cross member to front of rear cross member (4 ranks) | 4.83 ft (1.47 m) |
Press Wheels
| Steel (on 10-in spacing) | 3 x 21 in / 34.7 lb (7.6 x 53.3 cm / 15.7 kg), 4 x 22 in / 35.9 lb (10.2 x 55.9 cm / 16.3 kg) |
| Semi-pneumatic (on 10-in spacing) | 3 x 21 in / 37.2 lb (7.6 x 53.3 cm / 16.9 kg), 4 x 21 in / 41.8 lb (10.2 x 53.3 cm / 19 kg), 5.5 x 21 in / 51.6 lb (14 x 53.3 cm / 23.4 kg) |
| Split | 81.2 lb (36.8 kg) |
Tires
| Tire Code | 2210 | 2215 | 2220 |
|---|---|---|---|
| Wing configuration | Single | Dual | Dual |
| 1835-41,50 (12.50 & 15.20 m) Mainframe duals | 12.5L15 FI LR D | 12.5L15 FI LR D | 33×15.5-16.5 10 PR |
| 1835-41,50 (12.50 & 15.20 m) Wing | 12.5L15 FI LR D | 12.5L15 FI LR D | 31×13.5-15 10PR |
| 1835-61 (18.60 m) Mainframe duals | 12.5L15 FI LR F | 12.5L15 FI LR F | 33×15.5-16.5 10 PR |
| 1835-61 (18.60 m) Wing | 12.5L15 FI LR D | 12.5L15 FI LR D | 31×13.5-15 10 PR |
Tractor Requirements
| Tractor hydraulic SCVs (Minimum) | 3 |
| Tractor hydraulic circuit requirements | One selective control for frame lift; one selective control for wing fold and transport wheels, one for SFP rockshaft control |
| Tractor hydraulic pressure requirement | 41-ft: 2000 psi/min (138 bar/min) 50-ft: 2200 psi/min (151.7 bar/min) 61-ft: 2500 psi/min (172.4 bar/min) |
| Tractor Power for 41-ft. | 325 hp (242.35 kW) |
| Tractor Power for 50-ft | 400 hp (298.3 kW) |
| Tractor Power for 61-ft. | 475 hp (354.2 kW) |
