Dimensions
| Overall Length | 35.38 ft in (10782 mm) |
| Overall Width | 10.69 ft in (3260 mm) |
| Overall Height | 12.46 ft in (3797 mm) |
| Track Width | 8.27 ft in (2520 mm) |
| Wheelbase | 14.11 ft in (4300 mm) |
| Ground Clearance | 2.09 ft in (638 mm) |
| Dump Clearance | 3.09 ft in (941 mm) |
Dump
| Rated Payload | 69446 lb (31500 kg) |
| Capacity – Heaped | 26.16 yd3 (20 m3) |
| Lower Time | 13 sec |
| Raise Time | 11 sec |
Engine Details
| Number Of Cylinders | 6 |
| Engine Make | Iveco / FPT Industrial |
| Engine Model | Iveco Cursor 13 |
| Displacement | 781.2 cu in (12.8 L) |
| Bore | 5.31 in (135x mm) |
| Stroke | 5.30 in (150 mm) |
| Gross Power | 410 hp (302 kw) |
| Power Measured @ | 2100 rpm |
| Max Torque | 1364.5 lb ft (1850 Nm) |
| Torque Measured @ | 1400 rpm |
| Air Filter | Dry, with double cartridge |
| Aspiration | Turbocharger with intercooler |
| Emission Standards | CARB Off-Road / US EPA Tier 3 |
Operational Specs
| Empty Weight | 62832 lb (28500 kg) |
| Operating Weight | 132277 lb (60000 kg) |
| Operating Voltage | 24 V |
| Alternator | 90 amps |
| Battery | 2x 12 V, 70 Ah |
| Tire Size | 26.5R25 |
| Service Brakes | Hydraulic command dry disc brakes with gear pump powered by the engine and by 2 pressure accumulators |
| Parking Brake | Pneumatically controlled disc parking brake on rear tandem propeller shaft |
Transmission
| Transmission Type | Automatic ERGOPOWER ZF 6WG 310 drive transmission with 6 gears forward and 3 reverse |
| Torque Converter | Hydraulic torque converter, multiplication ratio (stall torque) 1:1.84 |
| Number of Gears | 6F / 3R |
| Max Travel Speed | 19 mph (30.6 km/h) |
Hydraulic System
| Type | Lload sensing system with variable displacement pump flanged to gearbox for steering and tipping |
| Pump | Hydraulic circuit fitting 2 pumps |
| Pump Flow | 97.4 gal/min (331 L/min) |
| Max Working Pressure | 3626 psi (25000 kPa) |
| Steering | Hydrostatic steering with Q-amp system by two double-acting cylinders |
Service Refill Capacities
| Fuel Tank Capacity | 105.7 gal (400 L) |
| Engine Oil Capacity (w/ Filter) | 9.2 gal (35 L) |
| Cooling System Capacity | 11.4 gal (43 L) |
| Hydraulic Tank Capacity | 63.4 gal (240 L) |
| Transmission Oil Capacity (w/ Filter) | 9.4 gal (35.5 L) |
| Front Differential Fluid Capacity | 3.7 gal (14 L) |
| Intermediate Axle Capacity | 9.0 gal (34 L) |
| Rear Axle Capacity | 8.7 gal (33 L) |
| Oil Hub (for hub) | 2.4 gal (9 L) |
