Dimensions
| Overall Length | 34.29 ft in (10450 mm) |
| Overall Width | 10.75 ft in (3275 mm) |
| Overall Height | 21.17 ft in (6450 mm) |
| Wheelbase | 17.59 ft in (5360 mm) |
| Dump Height | 21.17 ft in (6450 mm) |
| Dump Ground Clearance | 2.14 ft in (652 mm) |
| Ground Clearance | 1.93 ft in (587 mm) |
Dump
| Rated Payload | 71940 lb (32700 kg) |
| Capacity, Struck | 21 yd3 (16 m3) |
| Capacity, Heaped, 2:1 | 27 yd3 (21 m3) |
| Capacity, Heaped, 1:1 | 34 yd3 (26 m3) |
| Lower Time | 11 sec |
| Raise Time | 12 sec |
| Dump Angle | 70 degrees |
Weights
| Front Axle – Empty | 29480 lb (13400 kg) |
| Rear Axle – Empty | 29260 lb (13300 kg) |
| Total Empty | 58740 lb (26700 kg) |
| Front Axle – Loaded | 42900 lb (19500 kg) |
| Rear Axle – Loaded | 87780 lb (39900 kg) |
| Total Loaded | 130680 lb (59400 kg) |
Engine Details
| Number Of Cylinders | 6 |
| Engine Make | Scania |
| Engine Model | Scania DC12 |
| Displacement | 714 cu in (11.7 L) |
| Gross Power | 442.6 hp (330 kw) |
| Power Measured @ | 2200 rpm |
| Max Torque | 1140.3 lb ft (1546 Nm) |
| Torque Measured @ | 1600 rpm |
| Aspiration | Turbocharged |
Operational Specs
| Max Operating Weight | 130680 lb (59400 kg) |
| Pay Load | 71940 lb (32700 kg) |
| Operating Voltage | 24 V |
| Alternator | 100 amps |
| Battery | 2x 12 V, 225 Ah |
| Starter | 9 hp (6.7 kw) |
| Tire Size | 26.5R25 |
| Turning Radius according to ISO 7457 | 27.5 ft (8370 mm) |
Transmission
| Transmission Type | ZF 6 WG 310 Dash 4 electronically-controlled automatic |
| Number Of Forward Gears | 6 |
| Number Of Reverse Gears | 2 |
| Max Speed | 31.7 mph (51 km/h) |
Hydraulic System
| Type | 2x variable displacement piston pumps (for steering & tipping + for cooling, fan, brakes & auxilaries) |
| Max Pump Flow | 84.5 gal/min (320 L/min) |
| Relief Valve Setting, Tipping Circuit | 4061 psi (28000 kPa) |
| Relief Valve Setting, Steering Circuit | 3046 psi (21000 kPa) |
Service Refill Capacities
| Fuel Tank Capacity | 112.3 gal (425 L) |
| Cooling System Capacity | 13.3 gal (50 L) |
| Engine Oil Capacity | 3.5 gal (13.2 L) |
| Hydraulic System Capacity | 66.1 gal (250 L) |
| Transmission Fluid Capacity | 14.6 gal (55 L) |
