Dimensions
| Length W/ Blade | 19.06 ft in (5807 mm) |
| Width Over Tracks | 11.06 ft in (3371 mm) |
| Height To Top Of Cab | 11.99 ft in (3652 mm) |
| Length Of Track On Ground | 10.4 ft in (3167 mm) |
| Ground Clearance | 1.63 ft in (496 mm) |
| Length W/O Blade | 15.54 ft in (4736 mm) |
Undercarriage
| Track Gauge | 7.3 ft in (2225.04 mm) |
| Standard Shoe Size | 35.99 in (914 mm) |
| Number Of Shoes Per Side | 43 |
| Ground Pressure | 6.55 psi (45.17 kPa) |
| Ground Contact Area | 8973 in2 (5.79 m2) |
| Number Of Track Rollers Per Side | 7 |
Engine Details
| Number Of Cylinders | 6 |
| Engine Make | CAT |
| Engine Model | 3306T |
| Gross Power | 257 hp (191.7 kw) |
| Net Power | 240 hp (179 kw) |
| Power Measured @ | 2100 rpm |
| Displacement | 638 cu in (10.5 L) |
| Aspiration | Turbocharged |
Operational Specs
| Operating Weight | 59700 lb (27079.5 kg) |
| Fuel Tank Capacity | 126.6 gal (479 L) |
| Cooling System Fluid Capacity | 19.9 gal (75 L) |
| Engine Oil Capacity | 7.3 gal (27.3 L) |
| Hydraulic Fluid Capacity | 14.3 gal (54.1 L) |
| Powertrain Fluid Capacity | 47.1 gal (178 L) |
| Final Drives Fluid Capacity | 3.5 gal (13 L) |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 70 amps |
Transmission
| Transmission Type | Power Shift |
| Number Of Forward Gears | 3 |
| Number Of Reverse Gears | 3 |
| Max Speed – Forward | 6.8 mph (11 km/h) |
| Max Speed – Reverse | 8.6 mph (13.9 km/h) |
Hydraulic System
| Pump Type | Piston |
| Relief Valve Pressure | 3306 psi (22794.1 kPa) |
| Pump Flow Capacity | 46.8 gal/min (177 L/min) |
Standard Blade
| Width | 15 ft in (4545 mm) |
| Height | 52.9 in (1343 mm) |
| Capacity | 7.8 yd3 (5.9 m3) |
| Cutting Depth | 26.3 in (668 mm) |
