Hyster S100FT DM2 LP Forklift

Contents

Dimensions
Mast
Engine Details
Operational Specs

Dimensions

Length To Fork Face	9.09 ft in (2769 mm)
Overall Width	4.34 ft in (1320 mm)
Overall Height – Mast Lowered	7.02 ft in (2138 mm)
Wheelbase	5.88 ft in (1790 mm)
Ground Clearance	6.15 in (156 mm)
Height To Top Of Overhead Guard	7.14 ft in (2175 mm)
Max Fork Height	9.19 ft in (2800 mm)
Turning Radius	8.03 ft in (2447 mm)

Mast

Mast Tip Forward	5 degrees
Mast Tip Rear	6 degrees
Max Fork Spread	38.27 in (972 mm)
Lower Speed	82.7 ft/min (25.21 m/min)
Load Center	24.02 in (610 mm)
Load Capacity	10020.01 lb (4545 kg)
Lift Speed	112.2 ft/min (34.2 m/min)

Engine Details

Number Of Cylinders	6
Engine Make	General Motors
Engine Model	GM 4.3L
Power	98 hp (73.1 kw)
Torque	210 lb ft (284.8 Nm)
Power Measured @	2400 rpm
Displacement	262 cu in (4.3 L)
Torque Measured @	2400 rpm
Fuel Type	LP

Operational Specs

Operating Weight	16023.2 lb (7268 kg)
Tire Type	Cushion
Number Of Front Wheels	2
Number Of Rear Wheels	2
Max Speed	12.1 mph (19.5 km/h)
