Working Range
| Shipping Length | 48.69 ft in (14840 mm) |
| Shipping Height | 10.96 ft in (3340 mm) |
| Max Height | 43.31 ft in (13200 mm) |
| Max Reach At Ground Level | 37.73 ft in (11500 m) |
| Max Depth Below Ground | 13.13 ft in (4000 mm) |
| Boom/Arm Length | Under/Under |
Working Range (Boom/Arm Option 2)
| Shipping Length | 51.58 ft in (15720 mm) |
| Shipping Height | 10.96 ft in (3340 mm) |
| Max Height | 45.94 ft in (14000 mm) |
| Max Reach At Ground Level | 39.38 ft in (12000 mm) |
| Max Depth Below Ground | 15.59 ft in (4750 mm) |
| Boom/Arm Length | Over/Under |
Dimensions
| Overall Width | 11.88 ft in (3620 mm) |
| Length Of Track On Ground | 13.29 ft in (4050 mm) |
| Ground Clearance | 2.43 ft in (740 mm) |
| Tail Swing Radius | 9.91 ft in (3020 mm) |
| Height To Top Of Cab | 15.82 ft in (4820 mm) |
Undercarriage
| Track Gauge | 9.59 ft in (2920 mm) |
| Shoe Size | 27.56 in (700 mm) |
| Max Speed | 3.42 mph (5.5 km/h) |
Engine Details
| Number Of Cylinders | 6 |
| Engine Make | CAT |
| Engine Model | Cat C7 ACERT |
| Net Power | 204 hp (152.2 kw) |
| Power Measured @ | 1800 rpm |
| Displacement | 442 cu in (7.2 L) |
| Bore | 4.3 in (110 mm) |
| Stroke | 5.0 in (127 mm) |
| Aspiration | Turbocharged Aftercooled (TA) |
| Emission Standards | U.S. EPA Tier 3 and EU Stage IIIa |
Operational Specs
| Operating Weight | 83350 lb (37807 kg) |
| Operating Voltage | 24 V |
| Alternator | 80 amps |
| Working Lights | 4x Front working lights, cab top mounted + 2x Front working lights, riser mounted + 1x Left side working light, cab mounted + 1x Rear working light, cab mounted |
Swing Mechanism
| Swing Speed | 10 rpm |
| Swing Torque | 63664 lb ft (86317 Nm) |
Hydraulic
| Pump Flow Capacity | 124.2 gal/min (470 L/min) |
| Relief Valve Pressure | 5075 psi (35000 kPa) |
Service Refill Capacities
| Fuel Tank Capacity | 137.4 gal (520 L) |
| Engine Oil Capacity | 9 gal (34 L) |
| Cooling System Fluid Capacity | 8 gal (30 L) |
| Hydraulic System Fluid Capacity | 68.7 gal (260 L) |
