Dimensions
| Overall Width | 11.91 ft in (3630 mm) |
| Length Of Track On Ground | 14.67 ft in (4470 mm) |
| Track Gauge | 9.59 ft in (2920 mm) |
| Ground Clearance | 2.43 ft in (740 mm) |
| Overall Track Length | 17.92 ft in (5460 mm) |
| Overall Length | 605.12 in (15370 mm) |
| Tailswing Radius | 9.59 ft in (2920 mm) |
| Horizontal Reach | 38.16 ft in (11.63 m) |
| Transport Height | 12.08 ft in (3680 mm) |
| Width Over Tracks | 11.91 ft in (3630 mm) |
Undercarriage
| Carrier Rollers – Each Side | 2 |
| Track Rollers – Each Side | 8 |
| Track Shoe Width | 27.6 in (700 mm) |
| Ground Bearing Pressure | 11.6 psi (79.3 kPa) |
Engine Details
| Number Of Cylinders | 6 |
| Engine Make | John Deere PowerTech |
| Engine Model | John Deere PowerTech PSS 9.0L / PowerTech Plus 9.0 L |
| Displacement | 549 cu in (9.0 L) |
| Net Power | 271 hp (202 kw) |
| Power Measured @ | 1900 rpm |
| Aspiration | Turbocharged, air-to-air charge-air cooler |
| Emission Standards | EPA Final Tier 4 / EU Stage IV |
Operational Specs
| Lift Capacity At Max Reach | 18519 lb (8400 kg) |
| Swing Speed | 11.0 rpm |
| Swing Torque | 109500 lb ft (148462 Nm) |
| Operating Voltage | 24 V |
| Alternator | 150 amps |
| Work Lights (standard) | 14x LED Lamps |
| Service Lights | 5 LEDs (compartments) / 6 LEDs (compartments and riser) |
Powertrain
| Transmission Type | 2-speed propel with automatic shift |
| Maximum Travel Speed (Low) | 1.9 mph (3.0 km/h) |
| Maximum Travel Speed (High) | 2.4 mph (3.9 km/h) |
| Drawbar Pull | 79,590 lbf (36102 kgf) |
Weights
| Operating Weight | 105893 lb (48032 kg) |
| Counterweight, Heavy | 17582 lb (975 kg) |
| Side-Entry Forestry Cab | -1480 lb (-671 kg) |
| Non-LC Undercarriage | -1578 lb (-716 kg) |
Hydraulic System
| Type | Open center, pilot operated |
| Pump Type | Variable Axial Piston |
| Pump Flow | 80.3 gal/min (304 L/min) |
| Operating Pressure, Implement Circuits | 4975 psi (34300 kPa) |
| Operating Pressure, Power Boost | 5511 psi (38000 kPa) |
| Controls | Pilot levers; short-stroke, low-effort hydraulic pilot with shutoff lever |
Service Refill Capacities
| Fuel Tank Capacity | 285.4 gal (1080 L) |
| DEF Tank Capacity | 11.5 gal (43.6 L) |
| Cooling System Capacity | 10.5 gal (39.7 L) |
| Engine Oil Capacity (w/ Oil Filter) | 7.1 gal (27 L) |
| Hydraulic Tank Capacity | 51.6 gal (195 L) |
