Dimensions
| Overall Length | 42.29 ft in (12890 mm) |
| Overall Width | 11.38 ft in (3467 mm) |
| Overall Height | 12.16 ft in (3705 mm) |
| Wheelbase | 25.21 ft in (7684 mm) |
| Tractor Ground Clearance | 1.72 ft in (522 mm) |
| Height To Top Of Cab | 11.05 ft in (3366 mm) |
Weight
| Total Operating – Empty | 76437 lb (34671 kg) |
| Front Axle – Empty | 44754 lb (44754 kg) |
| Rear Axle – Empty | 31683 lb (31683 kg) |
| Total Operating – Loaded | 124438 lb (56444 kg) |
| Front Axel – Loaded | 60208 lb (27310 kg) |
| Rear Axle – Loaded | 64229 lb (64229. kg) |
Scraper Bowl
| Rated Payload | 48061 lb (21800 kg) |
| Heaped Capacity | 20.1 yd3 (15.3 m3) |
| Struck Capacity | 14 yd3 (10.7 m3) |
| Max Depth Of Cut | 13.2 in (333 mm) |
| Width Of Cut | 10 ft in (3023 mm) |
Engine Details
| Engine Make | CAT |
| Engine Model | Cat 3406 |
| Gross Power | 238 hp (177.5 kw) |
| Net Power | 225 hp (167.8 kw) |
| Power Measured @ | 2100 rpm |
| Displacement | 640.8 cu in (10.5 L) |
| Aspiration | Turbocharged |
Scraper Engine
| Engine Make | CAT |
| Engine Model | Cat 3306 |
| Gross Power | 246 hp (183.5 kw) |
| Net Power | 225 hp (167.8 kw) |
| Power Measured @ | 2200 rpm |
| Displacement | 640.8 cu in (10.5 L) |
| Aspiration | Turbocharged |
Operational Specs
| Operating Voltage | 24 V |
| Alternator (Tractor / Scraper) | 150 amps / 65 amps |
| Battery (Tractor / Scraper) | 4x 12V, CCA 1000 / 4x 12V, CCA 1000 |
| Tire Size (Tractor / Scraper) | 33.25-29 26PR (E-3) |
Transmission
| Number Of Forward Gears | 8 |
| Number Of Reverse Gears | 1 |
| Max Forward Speed | 35.8 mph (57.6 km/h) |
| Max Reverse Speed | 6.5 mph (10.4 km/h) |
Service Refill Capacities
| Fuel Tank Capacity | 208.7 gal (790 L) |
| Cooling System Fluid Capacity | 36.8 gal (139 L) |
| Engine Oil Fluid Capacity | 14.3 gal (54 L) |
| Transmission Fluid Capacity | 41 gal (155 L) |
| Differential Fluid Capacity | 37.8 gal (143 L) |
| Hydraulic System Fluid Capacity | 51.6 gal (195 L) |
| Wheel Coolant Fluid Capacity – Each | 23.8 gal (90 L) |
