Dimensions
| Overall Length | 255.6 in (6493 mm) |
| Width Over Tyres | 108.1 in (2745 mm) |
| Height to Top of Cab | 136.0 in (3455 mm) |
| Wheelbase | 127.6 in (3240 mm) |
| Ground Clearance | 21.89 in (556 mm) |
| Approach Angle | 30° |
| Maximum Articulation Angle | 45° |
Weight
| Weight | Empty | Loaded |
|---|---|---|
| Operating Weight | 27955 lb (12680 kg) | 37545 lb (17030 kg) GVM |
| Front Axle | 17571 lb (7970 kg) | 18078 lb (8200 kg) |
| Rear Axle | 10384 lb (4710 kg) | 19467 lb (8830 kg) |
| Gross Combination Mass (braked trailer) | 123459 lb (56000 kg) GCM |
Engine Details
| Number Of Cylinders | 6 |
| Engine Make | Mercedes Benz |
| Engine Model | Mercedes Benz OM906LA |
| Gross Power | 228 hp (170 kw) |
| Net Power | 219 hp (163 kw) |
| Power Measured @ | 2200 rpm |
| Gross Torque | 596 lb ft (810 Nm) |
| Net Torque | 574 lb ft (780 Nm) |
| Torque Measured @ | 1200-1600 rpm |
| Displacement | 389 cu in (6.37 L) |
| Bore | 4.0 in (102 mm) |
| Stroke | 5.1 in (130 mm) |
| Aspiration | Turbocharged and intercooled |
| Emission Standards | EPA Tier 2 / EU Stage II |
Transmission
| Transmission Model | ZF 6HP592C transmission with integral retarder |
| Gear Layout | Constant meshing planetary gears, clutch operated |
| Clutch Type | Hydraulically operated multi-disc |
| Torque Converter Layout | Hydrodynamic with lock-up in all gears |
| Number Of Forward Gears | 6 |
| Number Of Reverse Gears | 1 |
| Max Forward Speed | 30.2 mph (48.6 km/h) |
| Max Reverse Speed | 5.2 mph (8.3 km/h) |
| Drive | 4×4 Articulated Tractor |
Hydraulic System
| Type | Full load sensing system serving the prioritized steering, body tipping and brake functions |
| Pump Type | Variable displacement load sensing piston |
| Pump Flow Capacity | 48.6 gal/min (84 L/min) |
| Relief Valve Pressure | 3625 psi (25000 kPa) |
| Hydraulic Oil Filter | 10 microns |
Braking System
| Service Brake | Dual circuit, full hydraulic actuation caliper brakes on all wheels |
| Maximum Brake Force | 28241 lbf (125.6 kN) |
| Parking & Emergency Brake | Spring applied, air released driveline-mounted disc |
| Maximum Brake Force | 82824 lbf (368.4 kN) |
| Auxiliary Brake | Automatic exhaust brake and Engine Valve Brake (EVB) |
| Retarder | Integral transmission retarder with 6 settings |
Operational Specs
| Fuel Tank Capacity | 52.4 gal (198.5 L) |
| Operating Voltage | 24 V |
| Alternator | 80 amps, 28 V |
| Battery | 2x 12 V, 105 Ah |
| Tire Size | 23.5X25 SRG. Optional: 620/75R26; Dual 15X34 Traction |
| Internal Sound Level | 76 dB(A) ISO 6396 |
| Operator Seat | Adjustable, air suspension seat with retractable seat belt + Fold-away trainer seat with retractable seat belt |
