Dimensions
| Overall Length | 256.8 in (6523 mm) |
| Width Over Tyres (23.5R25) | 108.3 in (2752 mm) |
| Width Over Mudguards | 103.6 in (2632 mm) |
| Width Over Operating Mirrors | 128.3 in (3260 mm) |
| Height to Top of Cab | 137.5 in (3517 mm) |
| Height to Rotating Beacon | 143.5 in (3644 mm) |
| Wheelbase | 129.8 in (3296 mm) |
| Ground Clearance (Front Axle) | 19.29 in (490 mm) |
Weight
| Weight | Empty | Loaded |
|---|---|---|
| Operating Weight | 30688 lb (13920 kg) | 49383 lb (22400 kg) GVM |
| Front Axle | 20238 lb (9180 kg) | 24692 lb (11200 kg) |
| Rear Axle | 10450 lb (4740 kg) | 24692 lb (11200 kg) |
| Gross Combination Mass (braked trailer) | 123459 lb (56000 kg) GCM |
Engine Details
| Number Of Cylinders | 6 |
| Engine Make | Mercedes Benz |
| Engine Model | Mercedes Benz OM906LA |
| Gross Power | 275 hp (205 kw) |
| Net Power | 265 hp (198 kw) |
| Power Measured @ | 2200 rpm |
| Peak Torque | 811 lb ft (1100 Nm) |
| Torque Measured @ | 1200-1600 rpm |
| Displacement | 389 cu in (6.37 L) |
| Bore | 4.0 in (102 mm) |
| Stroke | 5.1 in (130 mm) |
| Aspiration | Turbocharged and intercooled |
| Emission Standards | EPA Tier 2 / EU Stage II |
Transmission
| Type | Fully automatic planetary transmission with optional retarder |
| Model | Allison 3500PR ORS |
| Gear Layout | Constant meshing planetary gears, clutch operated |
| Clutch Type | Hydraulically operated multi-disc |
| Torque Control | Hydrodynamic with lock-up in all gears |
| Number Of Forward Gears | 6 |
| Number Of Reverse Gears | 1 |
| Max Forward Speed | 27 mph (43 km/h) |
| Max Reverse Speed | 3 mph (6 km/h) |
| Drive | 4×4 Articulated Tractor |
| Maximum Articulation Angle | 45° |
| Approach Angle | 27° |
Hydraulic System
| Type | Full load sensing system serving the prioritized steering, body tipping and brake functions |
| Pump Type | Variable displacement load sensing piston |
| Pump Flow Capacity | 44 gal/min (165 L/min) |
| Relief Valve Pressure | 4061 psi (28000 kPa) |
| Hydraulic Oil Filter | 5 microns |
Braking System
| Service Brake | Dual circuit, full hydraulic actuation. Dry disc brakes with 6 calipers (4F, 2R) |
| Maximum Brake Force | 29675 lbf (132 kN) with standard tyres |
| Park & Emergency Brake | Spring applied air released, driveline mounted disc |
| Maximum Brake Force | 54400 lbf (242 kN) |
| Auxiliary Brake | Automatic exhaust valve brake and engine valve brake |
| Maximum Retardation | 221 hp (165 kw) Standard continuous / 724 hp (540 kw) with Maximium retarder option |
| Transmission Retarder | Optional automatic, adjustable, integral, hydrodynamic transmission retarder |
Operational Specs
| Fuel Tank Capacity | 100 gal (379 L) |
| Operating Voltage | 24 V |
| Alternator | 80 amps, 28 V |
| Battery | 2x 75 Ah AGM (Absorption Glass Mat) |
| Tire Size | 23.5R25 Radial Earthmover / Dual 15X34 Traction / 620/75 R26 Dual purpose (Traction and haulage) |
| Internal Sound Level | 74 dB(A) ISO 6396 |
| Operator Seat | Centre-mount air-suspension seat with retractable seat belt + Foldaway trainer seat with retractable seat belt |
