Dimensions
| Overall Length | 244 in (6197 mm) |
| Height To Top Of Cab | 96 in (2438 mm) |
| Width (axle) | 96 in (2430 mm) |
| Width (long axle) | 118.5 in (3000 mm) |
| Width (clearance lamps) | 137.3 in (3480 mm) |
| Width (extra-long lamps) | 175.1 in (4440 mm) |
| Wheelbase | 119 in (3020 mm) |
| Ground Clearance (rear axle) | 26.3 in (660 mm) |
| Ground Clearance (drawbar) | 13.9 in (353 mm) |
| Front Tire Size | 420/85R34 |
| Rear Tire Size | 480/80R50 |
Operational Specs
| Operating Weight | 27218 lb (12346 kg) |
| Max Operating Weight | 39683 lb (18000 kg) |
| Operating Voltage | 24 V |
| Alternator | 200 amps |
| Battery | 2x 12 V, CCA 925 |
Engine Details
| Number Of Cylinders | 6 |
| Engine Make | John Deere PowerTech |
| Engine Model | PowerTech PSX 9L John Deere 6090 HFG95 |
| Displacement | 549 cu in (9.0 L) |
| Gross Power | 396 hp (295 kw) |
| Net Power | 360 hp (268 kw) |
| Power Measured @ | 1800 rpm |
| Peak Torque | 1065 lb ft (1444 Nm) |
| Torque Measured @ | 1600 rpm |
| Torque Rise | 41.2 % |
| Aspiration | Turbocharged and air-to-air aftercooled |
| Emission Standards | US EPA Tier 4 Interim + Stage IIIB |
Power Take-off (PTO)
| Rear PTO | Independent |
| Rear PTO Type | 540/1000 |
| PTO Power | 355.4 hp (265 kw) |
Transmission
| Transmission Type | John Deere AutoPowr IVT (infinitely variable transmission) |
| Number of Forward Gears | infinite |
| Number of Reverse Gears | infinite |
| Max Travel Speed | 31 mph (49.9 km/h) |
Hydraulic System
| Type | Closed center pressure-flow compensated |
| Pump Flow Capacity | 35 gal/min (132.5 L/min) |
| Relief Valve Pressure | 2900 psi (20000 kPa) |
| Number Of Remote Control Valves | 3 to 5 |
| Rear 3 Point Hitch Type | 4N/3 |
| Rear 3 Point Hitch Lift Capacity @ 24 Inches | 19300 lb (8754 kg) *2011 year 20000 lb (9072 kg) **2012-2013 years |
| Front 3 Point Hitch Type | 3N/3 |
| Front 3 Point Hitch Lift Capacity @ 24 Inches | 8800 lb (3991 kg) 11450 lb (5193 kg) 12300 lb (5579 kg) |
Service Refill Capacities
| Fuel Tank Capacity | 183.6 gal (695 L) |
| Engine Oil Capacity | 7.4 gal (28 L) |
| Cooling System Capacity | 10.9 gal (41 L) |
| Hydraulic System Capacity | 68.3 gal (258.5 L) |
