Dimensions
| Wheelbase | 63.6 in (1610 mm) |
| Length | 120.8 in (3060 mm) |
| Width | 43.4 in (1100 mm) |
| Height with ROPS | 78.7 in (1990 mm) |
| Front Tread | 33.4 to 47.5 in (840 to 1200 mm) |
| Rear Tread | 35.1 to 49.9 in (890 to 1260 mm) |
| Front Axis Oscillation | 15° |
| Turning Radius, w/o Brakes | 88.6 in (2250 mm) |
| Turning Radius, w/ Brakes | 82.7 in (2100 mm) |
Operating Specs
| Operating Weight | 3351 lb (1520 kg) |
| Max Operating Weight | 5512 lb (2500 kg) |
| Tractor Type | Compact Utility Tractor |
| Cab | Two-post mid-mount folding ROPS |
| Operating Voltage | 12 V |
| Alternator | 45 amps |
| Battery | 12 V, 74 Ah |
| Starter | 12 V, 3. hp (2.2 kw) |
| Front Tire Size (Ag) | 200/70R16; 11,00/65-12 |
| Rear Tire Size (Ag) | 320/70R24; 380/70R20 |
Engine Details
| Number of Cylinders | 3 |
| Engine Make | Lombardini |
| Engine Model | Lombardini LDW 1603 |
| Displacement | 100.7 ci (1.7 L) |
| Bore | 3.46 in (88 mm) |
| Stroke | 3.54 in (90.4 mm) |
| Engine Power | 38 hp (28.3 kW) |
| Power Measured @ | 2800 rpm |
| Max Torque | 76.7 lb ft (104 Nm) |
| Torque Measured @ | 1650 rpm |
| Torque Reserve | 20% |
| Aspiration | Naturally aspirated |
PTO (Power Take-Off)
| PTO Type | Independent |
| Rear PTO Speed | 540 / 1000 |
| PTO Clutch | Dry |
Transmission
| Type | 12-speed synchronized transmission |
| Number of Gears | 12 forward + 12 reverse + 4 |
| Clutch | Mechanical dry disc, 9″ (229 mm) |
| Chassis | 4×4 MFWD 4WD |
| Min Travel Speed | 0.43 mph (0.7 km/h) |
| Max Travel Speed | 19 mph (30.6 km/h) |
Hydraulic System
| Type | Open center |
| Hydraulic Pressure | 2176 psi (15000 kPa) |
| Hydraulic Pump Flow | 8.7 gal/min (33 L/min) |
| Hydraulic Control Valves | 3 |
| 3 Point Hitch Type | I-IN |
| 3 Point Hitch Lift Capacity @ Lift Points | 3086 lb (1400 kg) |
| 3 Point Hitch Lift Capacity @ 24 Inches | 2205 lb (1000 kg) |
Service Refill Capacities
| Fuel Tank Capacity | 10.6 gal (40 L) |
| Engine Oil Capacity | 1.1 gal (4 L) |
| Cooling System Capacity | 1.6 gal (6 L) |
| Hydraulic / Transmission Oil Capacity | 6.3 gal (24 L) |
