Dimensions
| Overall Length w/o Blade | 304.0 in (7722 mm) |
| Wheelbase | 150.0 in (3810 mm) |
| Overall Width Over Tyres | 146.7 in (3727 mm) |
| Overall Height To Top of Cab | 150.6 in (3825 mm) |
| Height of Steering Wheel | 117.6 in (2987 mm) |
| Ground Clearance | 17.6 in (447 mm) |
Blades
| Type | Straight | U Blade | Coal |
|---|---|---|---|
| Blade Capacity | 7.2 yd3 (5.5 m3) | 9.8 yd3 (7.5. m3) | 19.5 yd3 (14.9 m3) |
| Blade Weight | 5100 lb (2313 kg) | 4300 lb (1950 kg) | 6000 lb (2722 kg) |
| Max Blade Tilt | 12.5 in (318 mm) | 12.5 in (318 mm) | 15.0 in (381 mm) |
| Max Raise Speed | 1.3 ft/sec (396 mm/sec) | 1.3 ft/sec (396 mm/sec) | 1.3 ft/sec (396 mm/sec) |
| Blade Width | 160 in (4064 mm) | 158 in (4013 mm) | 192 in (4877 mm) |
| Blade Height | 53 in (1346 mm) | 51 in (1295 mm) | 69 in (1753 mm) |
| Overall Length w/ Blade | 331 in (8407 mm) | 337 in (8560 mm) | 349 in (8852 mm) |
Engine Details
| Number Of Cylinders | 6 |
| Engine Make | Cummins |
| Engine Model | Cummins NTA 855C335 |
| Net Power | 302 hp (225.3 kw) |
| Power Measured @ | 2100 rpm |
| Peak Torque | 1005 lb ft (1363 Nm) |
| Torque Measured @ | 1400 rpm |
| Aspiration | Turbocharged + aftercooled |
| Displacement | 855 cu in (14.0 L) |
Operational Specs
| Max Weight (w/ Woodchip Blade & Counterweight) | 83310 lb (37789 kg) |
| Min Operating Weight (w/ U Blade) | 63700 lb (28894 kg) |
| Min Shipping Weight (w/ U Blade) | 62150 lb (28463 kg) |
| Operating Voltage | 24 V |
| Alternator | 100 amps |
| Work Lights | 4x 150W front work lights |
| Tire Size | 29.5-29 (22PR) L-3 |
| Noise Level in Cab | 86.3 dB(A) |
Service Refill Capacities
| Fuel Tank Capacity | 145 gal (549 L) |
| Cooling System Capacity | 21 gal (79.5 L) |
| Engine Oil Capacity | 11 gal (41.6 L) |
| Transmission Oil Capacity | 19.5 gal (73.8 L) |
| Hydraulic System Capacity | 110 gal (416.4 L) |
| Front Differential Oil Capacity | 12.75 gal (48.3 L) |
| Rear Differential Oil Capacity | 8.60 gal (32.6 L) |
| Front + Rear Wheel Hubs (each) | 3.25 gal (12.3 L) |
