Liebherr L 506ST Wheel Loader

Contents

Bucket
Dimensions
Engine Details
Operational Specs
Transmission

Bucket

Dump Clearance At Max Raise	8.14 ft in (2480 mm)
Bucket Width	5.91 ft in (1800 mm)
Bucket Capacity – Heaped	1.05 yd3 (0.8 m3)

Dimensions

Ground Clearance	0.99 ft in (300 mm)
Length With Bucket On Ground	17.08 ft in (5205 mm)
Width Over Tires	5.81 ft in (1770 mm)
Height To Top Of Cab	8.76 ft in (2670 mm)
Wheelbase	7.06 ft in (2150 mm)
Reach At Max Lift And Dump	2.76 ft in (840 mm)

Engine Details

Number Of Cylinders	4
Engine Make	Liebherr
Engine Model	D404T
Net Power	56.4 hp (42 kw)
Power Measured @	2800 rpm
Displacement	148.9 cu in (2.5 L)

Operational Specs

Operating Weight	11287.7 lb (5120 kg)
Static Tipping Weight	7123.2 lb (3231 kg)
Turning Radius	6.1 ft in (1845 mm)
Tire Size	365/70R18

Transmission

Transmission Type	Hydrostatic
Number Of Forward Gears	2
Number Of Reverse Gears	2
Max Speed – Forward	12.5 mph (20 km/h)
Max Speed – Reverse	12.5 mph (20 km/h)
